PD-L1 (E1L3N®) XP® Rabbit mAb (BSA and Azide Free)
一抗
单克隆抗体
R
Recombinant

PD-L1 (E1L3N®) XP® Rabbit mAb (BSA and Azide Free) #85164

Citations (3)
Filter:
  1. WB
  2. IHC
  3. F
Western blot analysis of extracts from KARPAS-299, SUP-M2, and PC-3 cells using PD-L1 (E1L3N®) XP® Rabbit mAb (upper) and β-Actin (D6A8) Rabbit mAb #8457 (lower). Data were generated using the standard formulation of this product.
Western blot analysis of extracts from A549 cells, IFN-γ treated (100 ng/mL, 48 hr; +) or untreated (-), using PD-L1 (E1L3N®) XP® Rabbit mAb (upper) or β-Actin (D6A8) Rabbit mAb #8457 (lower). Data were generated using the standard formulation of this product.
Immunohistochemical analysis of paraffin-embedded human non-small cell lung carcinoma using PD-L1 (E1L3N®) XP® Rabbit mAb performed on the Leica® BOND Rx. Data were generated using the standard formulation of this product.
Immunohistochemical analysis of paraffin-embedded human lung carcinoma using PD-L1 (E1L3N®) XP® Rabbit mAb. Data were generated using the standard formulation of this product.
Immunohistochemical analysis of paraffin-embedded human placenta using PD-L1 (E1L3N®) XP® Rabbit mAb in the presence of control peptide (left) or antigen-specific peptide (right). Data were generated using the standard formulation of this product.
Immunohistochemical analysis of paraffin-embedded Karpas-299 (left) or PC-3 (right) cell pellets using PD-L1 (E1L3N®) XP® Rabbit mAb. Data were generated using the standard formulation of this product.
Multiplex immunohistochemical analysis of paraffin-embedded human ovarian carcinoma using PD-L1 (E1L3N®) XP® rabbit mAb (red), CD8α (C8/144B) mouse mAb #70306 (magenta), B7-H4 (D1M8I) XP® rabbit mAb #14572 (green), FoxP3 (D2W8E) rabbit mAb #98377 (yellow), and Pan-keratin (C11) mouse mAb #4545 (cyan). Data were generated using the standard formulation of this product.
Multiplex immunohistochemical analysis of paraffin-embedded human ovarian carcinoma using PD-L1 (E1L3N®) XP® rabbit mAb (red), PD-L2 (D7U8C) XP® rabbit mAb (magenta) #82723, Arginase-1 (D4E3M) XP® rabbit mAb #93668 (green), IDO (D5J4E) rabbit mAb #86630 (yellow), CD68 (D4B9C) XP® rabbit mAb #76437 (orange), and Pan-keratin (C11) mouse mAb #4545 (cyan). Data were generated using the standard formulation of this product.
Multiplex immunohistochemical analysis of paraffin-embedded human breast carcinoma using PD-L1 (E1L3N®) XP® rabbit mAb (red), PD-1 (D4W2J) XP® rabbit mAb #86163 (green), LAG3 (D2G4O) XP® rabbit mAb #15372 (magenta), TIM-3 (D5D5R) XP® rabbit mAb #45208 (yellow), CD8α (C8/144B) mouse mAb #70306 (orange), and Pan-keratin (C11) mouse mAb #4545 (cyan). Data were generated using the standard formulation of this product.
Flow cytometric analysis of Ramos cells (blue) and Sup-M2 cells (green) using PD-L1 (E1L3N®) XP® Rabbit mAb (solid lines) or a concentration-matched Rabbit (DA1E) mAb IgG XP® Isotype Control #3900 (dashed lines). Anti-rabbit IgG (H+L), F(ab')2 Fragment (Alexa Fluor® 488 Conjugate) #4412 was used as a secondary antibody. Data were generated using the standard formulation of this product.
To Purchase # 85164SF
Cat. # Size Price Inventory
85164SF
100 µg

Supporting Data

REACTIVITY H
SENSITIVITY Endogenous
MW (kDa) 40-50
Source/Isotype Rabbit IgG

Application Key:

  • WB-Western Blot
  • IP-Immunoprecipitation
  • IHC-Immunohistochemistry
  • ChIP-Chromatin Immunoprecipitation
  • C&R-CUT&RUN
  • C&T-CUT&Tag
  • DB-Dot Blot
  • eCLIP-eCLIP
  • IF-Immunofluorescence
  • F-Flow Cytometry

Species Cross-Reactivity Key:

  • H-Human
  • M-Mouse
  • R-Rat
  • Hm-Hamster
  • Mk-Monkey
  • Vir-Virus
  • Mi-Mink
  • C-Chicken
  • Dm-D. melanogaster
  • X-Xenopus
  • Z-Zebrafish
  • B-Bovine
  • Dg-Dog
  • Pg-Pig
  • Sc-S. cerevisiae
  • Ce-C. elegans
  • Hr-Horse
  • GP-Guinea Pig
  • Rab-Rabbit
  • All-All Species Expected

Product Usage Information

This product is the carrier free version of product #13684. All data were generated using the same antibody clone in the standard formulation which contains BSA and glycerol.

This formulation is ideal for use with technologies requiring specialized or custom antibody labeling, including fluorophores, metals, lanthanides, and oligonucleotides. It is not recommended for ChIP, ChIP-seq, CUT&RUN, or CUT&Tag assays. If you require a carrier-free formulation for chromatin profiling, please contact us. Optimal dilutions/concentrations should be determined by the end user.

Formulation

Supplied in 1X PBS, BSA and Azide Free.

For standard formulation of this product see product #13684.

Storage

Store at -20°C. This product will freeze at -20°C so it is recommended to aliquot into single-use vials to avoid multiple freeze/thaw cycles. A slight precipitate may be present and can be dissolved by gently vortexing. This will not interfere with antibody performance.

Specificity / Sensitivity

PD-L1 (E1L3N®) XP® Rabbit mAb (BSA and Azide Free) recognizes endogenous levels of total PD-L1 protein.

Species Reactivity:

Human

Source / Purification

Monoclonal antibody is produced by immunizing animals with a synthetic peptide corresponding to residues near the carboxy terminus of human PD-L1 protein.

Background

Programmed cell death 1 ligand 1 (PD-L1, B7-H1, CD274) is a member of the B7 family of cell surface ligands that regulate T cell activation and immune responses. The PD-L1 ligand binds the PD-1 transmembrane receptor and inhibits T cell activation. PD-L1 was discovered following a search for novel B7 protein homologs and was later shown to be expressed by antigen presenting cells, activated T cells, and tissues including placenta, heart, and lung (1-3). Similar in structure to related B7 family members, PD-L1 protein contains extracellular IgV and IgC domains and a short, cytoplasmic region. Research studies demonstrate that PD-L1 is expressed in several tumor types, including melanoma, ovary, colon, lung, breast, and renal cell carcinomas (4-6). Expression of PD-L1 in cancer is associated with tumor-infiltrating lymphocytes, which mediate PD-L1 expression through the release of interferon gamma (7). Additional research links PD-L1 expression to cancers associated with viral infections (8,9).
